1325 150w 180w 280w 300w CO2 Laser Engraving And Cutting Machine

Get a Price/Quote

MOQ : 1 Unit

1325 150w 180w 280w 300w CO2 Laser Engraving And Cutting Machine Specification

Material
Stone

CNC Or Not
CNC

Computerized
No

Automatic Grade
Semi Automatic

Cooling Mode
Air Cooling

Voltage
220 Volt (v)

Feature
Lower Energy Consumption

Warranty
2-5 Years

Operating System
Android

Smart TV Features
Built-in WiFi, Screen Mirroring

USB Ports
2

Viewing Angle
178

Sleep Timer
Yes

Remote Battery Type
AAA

Refresh Rate
60 Hz

1325 150w 180w 280w 300w CO2 Laser Engraving And Cutting Machine Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cash in Advance (CID)

Supply Ability
50 Units Per Month

Delivery Time
7 - 10 Days

Main Domestic Market
All India

About 1325 150w 180w 280w 300w CO2 Laser Engraving And Cutting Machine

The 1325 150W 180W 280W 300W CO2 Laser Engraving and Cutting Machine is an advanced solution designed for precision engraving and cutting tasks. This semi-automatic machine operates at a 220-volt power supply and is ideal for working with materials like stone. Incorporating CNC technology, it ensures high accuracy and consistency in every operation. The machine is equipped with a lower energy consumption feature, making it an economical choice for businesses. With an air cooling mode, it maintains optimal performance and reliability during extended operations. Offered with a warranty ranging from 2 to 5 years, this machine provides robust durability and long-term value. Whether you are seeking to expand your production capacity or enhance precision, this laser engraving and cutting machine ensures exceptional efficiency and quality.

Specification :

X,Y,Z working area	1300*2500mm
Laser power	150w-180w RECI brand CO2 sealed glass laser tube(micro), life is 10000 hours
Cooling mode	Circulating-water-cooling, cw3000 industry chiller(FREE)
Power adjusting	0-100%controlling,no segment and adjusting by software
Machine control and drive	Speedy DSP controlling with LCD screen panel, stepper motor
motorized up and down working table	200-300mm(optional), if you need, the price will be USD 200 higher.
Rotating Axis	(USD 200), OPTIONAL
Engraving Speed	1-60000mm/min
Cutting speed	1-10000mm/min
Cutting thickness	0-20mm (non metal)
Support Graphic Format	.plt,.dst,.dxf,.bmp,.dwg,.al,*las, Support AutoCAD,CoreDraw, Photo shop, Tajima direct outputting
Position system	Red Point
Resolution ratio	0.05mm
Operating system	RD6332 control system
Resolution ratio	0.01mm
Location precision	0.01mm
PC interface	USB
Gross power	1.6kw
Power supply	220V10%/10A, 50 - 60Hz
Operating temperature	0-45
gross weight and package size	209016301640mm free fumigation wooden case	NET/GROSS WEIGHT: 1000KG/1200KG
Operating humidity	5%-80% free of condensed water
